70316-125*

* Contact Area Plated Spec.
1: Gold Flash
2: Gold Plated 0.127 Micrometers / 5 Microinch
3: Gold Plated 0.254 Micrometers / 10 Microinch
4: Gold Plated 0.381 Micrometers / 15 Microinch
5: Gold Plated 0.762 Micrometers / 30 Microinch
7: Bright Tin Plated 2.54 Micrometers / 100 Microinch Overall
8: Matte Tin Plated 2.54 Micrometers / 100 Microinch Overall
Product Inquiry
Product Specifications
Pitch 2.0 & 3.0mm
Circuit 4S/12P
Current Rating 1A/9.5A
Rating Voltage 600V
Mounting Type DIP
Contact Resistance 50mΩ/5mΩ
Color Black
Durability 30 times
Mating Series -
Technical Resources
3D File Member login
2D File
Specification
Package Spec

More Information

  1. The values specified in this website are only for reference.
    The products/specifications are subject to change without notice.
  2. We strongly suggest you to contact our sales for further information when considering use of any of the products in any other way than the recommended applications or for a specific use that requires an extremely high reliability.
